Battery Specifications
Operating Voltage Range(V) -10.0 ~ 14.6
Nominal Voltage (V) -12.8
Nominal Capacity(Ah) -300/C5
Energy (Wh) -3840
Charge Cut-off Voltage (V) -14.6 ± 0.2
Standard charging current 0.2C(A)-60
Rated charging current 0.5C(A)-150
Max. Charge current 1C(A) - 200
Reclog Voltage Disconnect(V)-10
Standard Discharge current 0.2C(A)-60
Rated Discharge Current 0.5C(A)-150
Max. Discharge current 1C (A) - 200
Maximum pulse current <3s(A) - 750
Internal Resistance (mΩ) ≤40
Charge Temperature℃) 0~55
Discharge Temperature (℃) -20 ~ 60
Storage Temperature (℃) -20 ~ 45
Cycle life (cycle @ 1C 100% DOD ) AT 25℃ ≥ 4000
Monthly self discharge Rate by 20-25 ℃ -<3%
IP Class - IP67
Weight (kg) - 30
Dimensions (mm) - 345 x 190 x 245
BMS -200A 4S/4P
Features
- Long cycle life
- High Energy density
- High discharge power
- Fast charging
- Wide temperature operating
- Low self-discharge
- Maintenance- free
